Functional Features
- Special Three-Load-Cell Support Structure: This unique design eliminates force point offset and signal distortion caused by uneven material distribution within the weighing hopper.
- Colorful Chinese Touch Screen Interface: The operation interface is intuitive and user-friendly. Functions are clearly displayed, reducing the probability of operational errors. The wide range of operable personnel means you no longer need to worry about selecting skilled operators.
- Manual Control Mode: Manual controls are provided for the bag-releasing, material-discharging, and bag-releasing mechanisms. This facilitates the clearing of clogged or agglomerated materials.
- Advanced High-Precision Components: Utilizes internationally renowned high-precision load cells and quantitative controllers. The controller features a high-performance A/D converter with a conversion rate of 240 times per second and an input sensitivity of 0.5μV/d, ensuring high weighing accuracy and excellent stability.
- Automatic Drop Correction & Tolerance Alarm: Features automatic drop correction and alarms for weight deviations outside the set tolerance.
- Simple Operation: Only one operator is required. The operator simply places the bag into the magazine; all subsequent actions—including bag pickup, filling, bagging, and sealing—are completed automatically.
